Internal threading insert TN metric 60°

Cod. 18891
Internal threading insert TN metric 60°

Insert TN for metric ISO threading 60°, right internal execution, full profile. Coating PVD T8030, highly versatile, medium cutting speeds; main application class ISO P35, M25, K30, secondary N25, S20, H20.

Code: 18891
Brand: IMPERO PRAMET
Category: Turning inserts
Type: Threading inserts
Applications: click here
Insert working mode:
Insert shape: TN
Tool type: Insert-handlers and Inserts
Tool Material: HM
Coating: PVD
Blockage system: S
Orientation: R
GB Code UM Description Note
18891100 NR INSERTS TN 16NR100M 60° T8030 P35, M25, K30
18891125 NR INSERTS TN 16NR125M 60° T8030 P35, M25, K30
18891150 NR INSERTS TN 16NR150M 60° T8030 P35, M25, K30
18891175 NR INSERTS TN 16NR175M 60° T8030 P35, M25, K30
18891200 NR INSERTS TN 16NR200M 60° T8030 P35, M25, K30
18891250 NR INSERTS TN 16NR250M 60° T8030 P35, M25, K30
18891300 NR INSERTS TN 16NR300M 60° T8030 P35, M25, K30
data sheet Internal threading insert TN metric 60°
GB Code Description
18858 SIR toolholder for internal threading
