HSS-Co staggered-toothed side and face cutter

Side and face milling cutter with stuggered teeth for slotting, HSS-Co5% or PMCo8,5% steel depending on stock availability, UNI 3905A, DIN 885A, ISO 2587. Cutting edge profile H for the machining of high-alloyed materials.

Code: 14430

Brand: GB

Category: End mills

Type: Shell cutters

Applications: click here

Helix - Rake: None

Flutes Number: 16 18 20 22 24 26

Lengths: Short

Tool Material: HSS-Co

Use: Face

Coating: None

Flutes profile: N

Speed: normal

Order Print technical sheet

GB Code	UM	Description	Note
14430080	NR	SIDE CUTTERS 14430 50X 4X16 staggered teeth HSSCo **ì	can only be ordered on request
14430095	NR	SIDE CUTTERS 14430 50X 6X16 staggered teeth HSSCo **	can only be ordered on request
14430110	NR	SIDE CUTTERS 14430 50X 8X16 staggered teeth HSSCo **	can only be ordered on request
14430125	NR	SIDE CUTTERS 14430 50X10X16 staggered teeth PMCo8,,5 **	can only be ordered on request
14430140	NR	SIDE CUTTERS 14430 63X 4X22 staggered teeth HSSCo **	can only be ordered on request
14430155	NR	SIDE CUTTERS 14430 63X 5X22 staggered teeth PMCo8,5 **	can only be ordered on request
14430170	NR	SIDE CUTTERS 14430 63X 6X22 staggered teeth HSSCo **	can only be ordered on request
14430185	NR	SIDE CUTTERS 14430 63X 8X22 staggered teeth HSSCo **	can only be ordered on request
14430200	NR	SIDE CUTTERS 14430 63X10X22 staggered teeth HSSCo **	can only be ordered on request
14430215	NR	SIDE CUTTERS 14430 63X12X22 staggered teeth PMCo8,5 **	can only be ordered on request
14430230	NR	SIDE CUTTERS 14430 80X 6X22 staggered teeth HSSCo **	can only be ordered on request
14430245	NR	SIDE CUTTERS 14430 80X 8X22 staggered teeth HSSCo **	can only be ordered on request
14430260	NR	SIDE CUTTERS 14430 80X10X22 staggered teeth HSSCo **	can only be ordered on request
14430275	NR	SIDE CUTTERS 14430 80X12X22 staggered teeth HSSCo **	can only be ordered on request
14430290	NR	SIDE CUTTERS 14430 80X12X27 staggered teeth HSSCo **	can only be ordered on request
14430305	NR	SIDE CUTTERS 14430 80X14X22 staggered teeth PMCo8,5 **	can only be ordered on request
14430320	NR	SIDE CUTTERS 14430 80X16X22 staggered teeth HSSCo **	can only be ordered on request
14430335	NR	SIDE CUTTERS 14430 80X20X22 staggered teeth PMCo8,5 **	can only be ordered on request
14430350	NR	SIDE CUTTERS 14430 100X 6X27 staggered teeth PMCo8,5 **	can only be ordered on request
14430365	NR	SIDE CUTTERS 14430 100X 7X32 staggered teeth PMCo8,5 **	can only be ordered on request
14430380	NR	SIDE CUTTERS 14430 100X 8X32 staggered teeth PMCo8,5 **	can only be ordered on request
14430395	NR	SIDE CUTTERS 14430 100X10X27 staggered teeth PMCo8,5 **	can only be ordered on request
14430410	NR	SIDE CUTTERS 14430 100X10X32 staggered teeth PMCo8,5 **	can only be ordered on request
14430425	NR	SIDE CUTTERS 14430 100X12X32 staggered teeth PMCo8,5 **	can only be ordered on request
14430440	NR	SIDE CUTTERS 14430 125X 8X32 staggered teeth PMCo8,5 **	can only be ordered on request
14430455	NR	SIDE CUTTERS 14430 125X10X32 staggered teeth HSSCo **	can only be ordered on request
14430470	NR	SIDE CUTTERS 14430 125X12X32 staggered teeth HSSCo **	can only be ordered on request
14430485	NR	SIDE CUTTERS 14430 125X22X32 staggered teeth PMCo8,5 **	can only be ordered on request

data sheet HSS-Co staggered-toothed side and face cutter
