Cod. 13636
HM HSC torus micro end mill, coated
2 flute torus micro end mill for deep ribs, solid carbide HM HSC (High Speed Cutting) with Ti and Al based multi-coating Skin-3 for milling of hard and tough materials. Micro series for mold makers with HSC cutting edge profile for machining hardened steels up to 65 HRC, cylindrical shank. Other dimensions, lengths and radii are available upon request.
Code: 13636
Brand: GB
Category: End mills
Type: Microcutter
Applications: click here
Helix - Rake: None
Flutes Number: 2
Lengths: Not specified
Tool Material: HM
Use: Side/Face
Coating: Multi-coated
Flutes profile: H HSC
Speed: high speed
| GB Code | UM | Description | Note |
|---|---|---|---|
| 13636054 | NR | MICRO END MILLS 13636 0,5- 4 r0,10 Z.2 Toric HSC HM HSC Skin3 | |
| 13636056 | NR | MICRO END MILLS 13636 0,5- 6 r0,10 Z.2 Toric HSC HM HSC Skin3 | |
| 13636064 | NR | MICRO END MILLS 13636 0,6- 4 r0,10 Z.2 Toric HSC HM HSC Skin3 | |
| 13636066 | NR | MICRO END MILLS 13636 0,6- 6 r0,10 Z.2 Toric HSC HM HSC Skin3 | |
| 13636084 | NR | MICRO END MILLS 13636 0,8- 4 r0,10 Z.2 Toric HSC HM HSC Skin3 | |
| 13636086 | NR | MICRO END MILLS 13636 0,8- 6 r0,10 Z.2 Toric HSC HM HSC Skin3 | |
| 13636100 | NR | MICRO END MILLS 13636 1,0- 5 r0,10 Z.2 Toric HSC HM HSC Skin3 | |
| 13636104 | NR | MICRO END MILLS 13636 1,0-10 r0,10 Z.2 Toric HSC HM HSC Skin3 | |
| 13636150 | NR | MICRO END MILLS 13636 1,5- 8 r0,15 Z.2 Toric HSC HM HSC Skin3 | |
| 13636154 | NR | MICRO END MILLS 13636 1,5-12 r0,15 Z.2 Toric HSC HM HSC Skin3 | |
| 13636200 | NR | MICRO END MILLS 13636 2,0-10 r0,20 Z.2 Toric HSC HM HSC Skin3 | |
| 13636202 | NR | MICRO END MILLS 13636 2,0-12 r0,20 Z.2 Toric HSC HM HSC Skin3 | |
| 13636204 | NR | MICRO END MILLS 13636 2,0-16 r0,20 Z.2 Toric HSC HM HSC Skin3 | |
| 13636206 | NR | MICRO END MILLS 13636 2,0-20 r0,20 Z.2 Toric HSC HM HSC Skin3 | |
| 13636250 | NR | MICRO END MILLS 13636 2,5-13 r0,25 Z.2 Toric HSC HM HSC Skin3 | |
| 13636300 | NR | MICRO END MILLS 13636 3,0- 8 r0,30 Z.2 Toric HSC HM HSC Skin3 | |
| 13636302 | NR | MICRO END MILLS 13636 3,0-12 r0,30 Z.2 Toric HSC HM HSC Skin3 | |
| 13636304 | NR | MICRO END MILLS 13636 3,0-16 r0,30 Z.2 Toric HSC HM HSC Skin3 | |
| 13636306 | NR | MICRO END MILLS 13636 3,0-20 r0,30 Z.2 Toric HSC HM HSC Skin3 | |
| 13636400 | NR | MICRO END MILLS 13636 4,0-12 r0,40 Z.2 Toric HSC HM HSC Skin3 | |
| 13636404 | NR | MICRO END MILLS 13636 4,0-16 r0,40 Z.2 Toric HSC HM HSC Skin3 | |
| 13636406 | NR | MICRO END MILLS 13636 4,0-20 r0,40 Z.2 Toric HSC HM HSC Skin3 |
